PDF version

{{item.title}} {{item.zycontent}}
Lang Version Date Size Format
X14 Product Brochure EN V1.4 1/10/2020 12:00:00 AM 2.0MB PDF
X14 Custom Specification EN V1.3 9/22/2020 12:00:00 AM 729KB PDF
X14 Quick Start EN V1.0 7/9/2019 12:00:00 AM 6.0MB PDF
X14 User Manual EN V1.1 1/16/2020 12:00:00 AM 7.0MB PDF
X Series-CE LVD Certificate EN V1.0 8/24/2021 11:54:22 AM 745KB PDF
X Series-CE EMC Certificate EN V1.0 7/4/2019 12:00:00 AM 845KB PDF
X Series RoHS Certificate EN V1.0 7/10/2019 12:00:00 AM 766KB PDF
X Series FCC Certificate EN V1.0 7/4/2019 12:00:00 AM 910KB PDF
X14 is configurable and controllable from XPOSE.
XPOSE logo
Download the latest release of XPOSE HERE
There is no specific software for X14
X14 Firmware EN V1.46 11/10/2020 12:00:00 AM 168.0MB ZIP
Product Code Model Description
190-0014-03-0 Quad 3G D-SDI Input Module
190-0014-04-0 [email protected] Digital Input Module
190-0014-05-0 12G SDI Input Module Go to
190-0014-06-0 Quad HDBaseT Input Module
190-0014-20-0 X14 Output EXT Interface
190-0014-02-0 Quad 2K D-HDMI Input Module
190-0014-07-0 Quad H.264 Input Module
190-0014-00-0 X14 Input EXT Interface
190-0014-21-0 Quad DVI Output Module
190-0014-22-0 Quad 2K HDMI Output Module
190-0014-23-0 Quad 3G SDI Output Module
190-0014-24-0 Quad HDBaseT Output Module
190-0014-25-0 H.264 Output Module
190-0014-26-0 Dual 4K HDMI Output Module
190-0014-27-0 ARO Rotation Module
950-0006-00-0 Power Supply 1200W
190-0014-28-0 Dual HDMI 4K Multi-Layer Ouptut Module Go to
